LOG STL Antenne 800-2700Mhz

LogPeriodic GHz Microwave Antenna 800-2700 Mhz, 9 dBi, 30W, NF connector

The LOG STL Antenna is an easy-to-install antenna specifically designed STL applications.
It operates over a wide range of frequencies: 800-2700Mhz.

Frequency 800÷2700MHz
Impedance 50 Ohm
VSWR <1,7
Gain 9÷11dBi

Front To Back Ratio >15dB
Polarization V or H
Light Protection All Parts Direct Grounded

Wind survival 130Km/h
Material Aluminium
Rf Power 30W
Connector NF
Number of elemets 19
Lenght 870 mm
Width 190 mm
Weight 0,8Kg

LogPeriodic Ghz Microwave Antenna 800-2700Mhz

This antenna is solidly built and can withstand wind and weather well.
