LOW POWER TV TRANSMITTERS

The ETVD Series of Low Power TV Transmitters – Transposers – Gap-fillers is the ultimate in technology, quality and performance

Main Characteristics- Available in all Analogue standards ( PAL, SECAM, NTSC ) with digital processing for high performances – Available in all Digital standards (DVB-T/T2, ISDB-T/Tb, ATSC ) – Available in band I – III – IV – V- From 25Wrms to 150Wrms with LDMOS technology- Integrated Linear & Non-Linear Adaptive Precorrector- 2 ASI inputs with seamless and priority- IP-to-ASI input option- MFN or SFN networks application- Internal GPS receiver – Gap Filler with Hi-Efficiency Echo canceller- Web Server, SNMP Protocol

GENERAL Frequency Range Band I, III, IV, V Channel Bandwidth 6, 7, 8 MHz RF Load Impedance 50 ohms, 1.1:1 VSWR over any single TV channel RF Output Connector N or 7/16 AC MAINS AC Line Voltage 2-phase 50/60 Hz, 100V to 240V AC Line Variation 10% to -15% Power Factor > 0.97 Power consumption 641.2VA @max output COFDM ENVIRONMENTAL Altitude Up to 4,000m above sea level Ambient Temperature 14º to 113º F (-10º to 45º C) at sea level Humidity Up to 95%, non-condensing Cooling Method Forced Air Acoustic Noise < 65 dBA (measured 1m in front of cabinet) ANALOG Tv Standards B/G/D/K/K1/M/N Colour Systems PAL, NTSC Video Input Interfaces 2 BNC 75Ω, 1Vpp±6 dB. Modulation Depth 5÷15 % Audio Input Interfaces 2 XLR 600Ω/5 KΩ, balanced / unbalanced, 0dBm -6dB +21dB Audio encoder mode Mono/Stereo/Dual Sound Fm Deviation Up to 100 KHz (200 KHz for standard M), Hard Limiter 1KHz step Power Output up to 600Wps Output Power Reduction 0 to -10dB ECHO CANCELLER (optional) Cancellation Level 30dB Maximum Echo Level + 15dBc (Over the main signal) RF Sample Level 0dBm for transposer nominal power MECHANICAL Dimensions (WxHxD) Weight (approx.) mm 484x90x550 Kg 19 COFDM: DVB-T/T2, ISDB-T/Tb (SBTVD) Systems ISDB-T, ISDB-Tb, DVB-T, DVB-T2 Digital Inputs ISDB-T/Tb: 3 BNC 75Ω ASI (Hierarchical up to 3 Layers) DVB-T/T2: 2 BNC 75 Ω, DVB-ASI (Hierarchical) IP-To-ASI: RJ45 Crest Factor Maximum 13 dB Shoulder Level > 40dB MER > 37dB Harmonics (before filter) < -40dB Central Carrier Suppression > 75dB Frequency Stability (without ext. ref.) ± 150 Hz/month Frequency Offsets 1 Hz resolution MPEG packet length 188/204 byte packets, continuous and burst Network Operations MFN, SFN Optional Output filter (NCM) with insertion loss 0.3 dB @ F.C. 0.7 dB @ F.C. ± 3.8 MHz Power Output up to 150Wrms Output Power Reduction 0 to -10 dB 8-VSB: ATSC System ATSC A-53, 8-VSB DTV standard Digital Input 2 BNC 75 Ω ASI (SMPTE 310M) Internal Precise Frequency input 10 MHz (1) Internal Gps Receiver Optional Phase Noise < 104 dBc/Hz @ 20 kHz offset (ATSC A/64) Pilot Frequency Stability Less than ±150 Hz/month Less than ±3 Hz with internal or external PFC Harmonic Radiation and Spurious Meets mask requirements specified in FCC 5th and 6th report and order Sideband Performance Compliant with FCC radiation mask, when measured at the output of optional output filter Optional output filter with insertion loss 0,3 dB @ F.C. 0,5 dB @ F.C. ± 2,7 Mhz Power Output up to 225Wrms Output Power Reduction 0 to -10 dB
