COMBINERS STARPOINT
Description
COMBINERS STARPOINT
FM STARPOINT, DOUBLE COAXIAL FILTERS COMBINERS
Made of aluminum, silvered copper and PTFE.
They are composed of two or more cavity filters connected together by rigid lines, so we will have all inputs selective. It is therefore necessary , in order, knowing all the frequencies of use.
| /402S | /2000S | /2000S-H | /4000S | /6000S | /10000S | ||
|---|---|---|---|---|---|---|---|
| FREQ. RANGE | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz |
| IMPEDANCE | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm |
| V.S.W.R. | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 |
| ATTENUATION | < 0.4db | < 0.5db | < 0.5db | < 0.5db | < 0.3db | < 0.3db | < 0.2db |
| MIN. CHANNELS SPACING | >5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz |
| ISOLATION BETWEEN CHANNELS | 35db typical | 35db typical | 35db typical | 35db typical | 35db typical | 35db typical | 35db typical |
| BANDWIDTH ( -3db ) | 200Khz | 500Khz | 300-600Khz | 300-600Khz | 300 – 600Khz | 300 – 600Khz | 300 – 600Khz |
| WORKING TEMPERATURE | 10-40° | 10-40° | 10-40° | 10-40° | 10-40° | 10-40° | 10-40° |
| CONNECTOR IN | N | N | N | 7/16 | 7/16 | 7/8 | 7/8 |
| CONNECTOR OUT | N | N | 7/16 | 7/8 | 78 | 1 5/8 | 1 5/8 |
| POWER | 2X100W | 2X200W | 2X500W | 2X1KW | 2X2KW | 2X3KW | 2X5KW |
| WEIGHT | 10.6 Kg | 20.7 Kg | 22.5 Kg | 24 Kg | 37 Kg | 40.5 Kg | 53 Kg |
| DIMENSIONS (cm) |
80x49x13 | 80x49x26 | 115x42x27 | 115x42x30 | 130x41x40 | 130x41x40 | 135x62x50 |
TRIPLEXERS ( /602S MODEL RACK 19″ ):
| /602S | /3000S | /3000S-H | /4500S | /60000S | /7500S | |
|---|---|---|---|---|---|---|
| FREQ. RANGE | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz | 87.5 – 108Mhz |
| IMPEDANCE | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm | 50 Ohm |
| V.S.W.R. | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 | <1.15:1 |
| ATTENUATION | < 0.5db | < 0.5db | < 0.5db | < 0.4db | < 0.4 db | < 0.4 db |
| MIN. CHANNELS SPACING | >2.5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz | >2.5Mhz |
| ISOLATION BETWEEN CHANNELS | 35db typical | 35db typical | 35db typical | 35db typical | 35db typical | 35db typical |
| BANDWIDTH ( -3db ) | 500Khz | 300 – 600Khz | 300 – 600Khz | 300 – 600Khz | 300 – 600Khz | 300 – 600Khz |
| WORKING TEMPERATURE | 10-40° | 10-40° | 10-40° | 10-40° | 10-40° | 10-40° |
| CONNECTOR IN | N | N | 7/16 | 7/16 | 7/16 | 7/8 |
| CONNECTOR OUT | 7/16 | 7/16 | 7/8 | 1 5/8 | 1 5/8 | 1 5/8 |
| POWER | 3X200W | 3X500W | 3X800W | 3X1.5KW | 3X2KW | 3X2.5KW |
| WEIGHT | 36 Kg | 33 Kg | 33 Kg | 56 Kg | 58.5 Kg | 60 Kg |
| DIMENSIONS (cm) |
80x49x39 | 115x62x27 | 115x62x27 | 130x62x41 | 130x62x41 | 130x62x41 |
QUADRIPLEXERS :
| /2000S | /2000S-h | ||
|---|---|---|---|
| FREQ. RANGE | 87.5 – 108Mhz | 87.5 – 108Mhz | |
| IMPEDANCE | 50 Ohm | 50 Ohm | |
| V.S.W.R. | <1.15:1 | <1.15:1 | |
| ATTENUATION | < 0.6db | < 0.6db | |
| MIN. CHANNELS SPACING | >2.5Mhz | >2.5Mhz | |
| ISOLATION BETWEEN CHANNELS |
35 db typical | 35 db typical | |
| BANDWIDTH ( -3db ) | 300 – 600Khz | 300 – 600Khz | |
| WORKING TEMPERATURE | 10-40° | 10-40° | |
| CONNECTOR IN | N | 7/16 | |
| CONNECTOR OUT | 7/8 | 7/8 | |
| POWER | 4x300W | 4x500W | |
| WEIGHT | 46 Kg | 47 Kg | |
| DIMENSIONS (cm) | ……. | 115x54x41 | 115x54x41 |
