100W FM Exciter
BROADCAST E100 – FM 100W FM Exciter/Transmitter
100W FM Exciter ( 100W/Mono/MPX/2HE)Low Power FM transmitter Compact Eletec 100 Watt exciter with Mono and MPX input
Description
BROADCAST E100 – 100W FM Exciter
FREQUENCY RANGE 87.5 ÷ 108 MHz
MODULATION FM
EMISSION CLASS F3E
VCO TUNING 25 MHz
FREQUENCY STABILITY ± 2.5 ppm
SYNTHESIZER STEP 100KHz opz. 10KHz
POWER OUTPUT 0 ÷ 100 Watt
SPURIOUS EMISSION < – 80 dB or better
HARMONIC EMISSION < – 70 dB
STEREO SEPARATION > 55 dB @ 1KHz (typ. 60dB)
DISTORSION < 0.1 % (typ. 0.06%) @ 1KHz
BASE BAND 30 Hz ÷ 60 KHz within 0.15 dB
UNWEIGHTED S/N RATIO >80 dB (30Hz ÷ 15KHz 50 µS RMS)
ASYNCRONOUS AM S/N Ratio > 65 dB Ref. 100% AM 400Hz
SYNCRONOUS AM S/N Ratio > 65 dB with FM @ 75KHz @400Hz
PRE-ENPHASIS 50 OR 75 µS int. selectable
RF OUT CONNECTOR N-F 50 Ohm
MPX INPUT CONNECTOR BNC-F
MPX INPUT IMPEDANCE 2 KOhm
SCA INPUT CONNECTOR 3 BNC-F
COOLING Forced Air
OP.TEMPERATURE RANGE -10 ÷ 45 °C
MAXIMUM HUMIDITY 90 %
AC SUPPLY 115 ÷ 240 VAC – 47 ÷ 63 Hz
DIMENSION 3 unit rack 19″, 360mm depth
WEIGHT 12 Kg
MODULATION FM
EMISSION CLASS F3E
VCO TUNING 25 MHz
FREQUENCY STABILITY ± 2.5 ppm
SYNTHESIZER STEP 100KHz opz. 10KHz
POWER OUTPUT 0 ÷ 100 Watt
SPURIOUS EMISSION < – 80 dB or better
HARMONIC EMISSION < – 70 dB
STEREO SEPARATION > 55 dB @ 1KHz (typ. 60dB)
DISTORSION < 0.1 % (typ. 0.06%) @ 1KHz
BASE BAND 30 Hz ÷ 60 KHz within 0.15 dB
UNWEIGHTED S/N RATIO >80 dB (30Hz ÷ 15KHz 50 µS RMS)
ASYNCRONOUS AM S/N Ratio > 65 dB Ref. 100% AM 400Hz
SYNCRONOUS AM S/N Ratio > 65 dB with FM @ 75KHz @400Hz
PRE-ENPHASIS 50 OR 75 µS int. selectable
RF OUT CONNECTOR N-F 50 Ohm
MPX INPUT CONNECTOR BNC-F
MPX INPUT IMPEDANCE 2 KOhm
SCA INPUT CONNECTOR 3 BNC-F
COOLING Forced Air
OP.TEMPERATURE RANGE -10 ÷ 45 °C
MAXIMUM HUMIDITY 90 %
AC SUPPLY 115 ÷ 240 VAC – 47 ÷ 63 Hz
DIMENSION 3 unit rack 19″, 360mm depth
WEIGHT 12 Kg
100W Professional FM Broadcast Transmitter
