400W UHF TRANSMITTER

Description

400W UHF TRANSMITTER

400W UHF TV Transmitter, low cost series  TV transmitters for small TV stations. Build your own TV studio and broadcast your own TV program! Transmit  or re-transmit the TV program you’ve never been able to receive in your valley, run a college TV station, cover rural areas of Africa with TV signal from satellite stations

This UHF TV Transmitter offers 400W of power in the low UHF band. Unit is rugged and made for 24/7/365 operation. It gives from several km to about 30km of range depending on antenna type used on transmitting and receiving side.



General features:

– Built-in CPU for controlling and monitoring
– Adjustable TV channel (via LCD module with up/down keys)
– Easily adjustable TV and sound standard (via LCD module)
– Built-in test signal generator
– Supports all analog world TV standards: All PAL versions, SECAM, NTSC
– SWR protection
– Stereo sound possible with stereo board
– Friendly user interface
– Output power model LOW UHF: 400W typ at the bottom of UHF band and falling towards the top, adjustable from LCD
– Output power model FULL UHF: 400W typ across entire UHF band, adjustable from LCD
– Output impedance 50 Unbalanced, VSWR less than 2:1 for full output
– Output connector BNC female ( rear panel )
– Frequency range: TV UHF entire band
– Audio connectors: RCA (cinch)
– Audio level: 1Vpp
– Video level: 1Vpp
– Audio input impedance: 10K resistive, unbalanced
– Power supply: mains power supply 110-240V/50-60Hz universal, PC style mains cable
– Uses our standard 19″ 2H rack
– Weight 12kg
